Sc APC Upc Fiber Optic Adapter Singlemode Multimode Square Solid Metal Adapter Coupler

Product Categories

Jiangsu Dierite Optoelectronics Technology Co.,Ltd.

Contact Now

Sc APC Upc Fiber Optic Adapter Singlemode Multimode Square Solid Metal Adapter Coupler

Certification : CE, ISO, RoHS

Application : Fiber Distribution Frame, Network Equipment, Fiber Module, Fiber Distribution Frame, Network Equipment, Fiber Module

Light Source TYPE : Passive

Connector Type : SC-PC, Sc-PC

Brand : OEM, OEM

Condition : New

Wiring Devices : ODF

Use : FTTH

Mode : Singlemode/Multimode/Om3/Om4/APC

Channel : Simplex/Duplex

Material : Metal, Plastic

Type : Fiber Optic Adapter

Transport Package : Wooden-Drum

Specification : FC-FC APC

Trademark : Dierite

Origin : Changzhou Jiangsu China(Mainland)

Supply Ability : 200000PCS/Month

Transmission Medium : Single-Mode, Single-Mode

Structure : SC, Sc

Number of Cores : Single-Core, Single-Core

Ferrule Endface : PC(UPC), PC(Upc)

Shape : Square, Square

Fabrication Process : Moulded, Moulded

Samples : US$ 0/Piece 1 Piece(Min.Order) | Request Sample

Customization : Available | Customized Request

Contact Now

Product Description

Sm Fiber Optic Cable Sc APC Upc Simplex Singlemode&Multimode Square Solid Metal Adapter/Coupler Sc/APC

Technical parameter

Parameter	Unit	Description
Parameter	Unit	SM/UPC	SM/APC	MM
Sleeve		Zirconia	Zirconia	Phosphor Bronze
Operation wavelength	nm	1310 or 1550		850
Insertion loss	dB	0.2	0.2	0.2
Connection durability	Times	1000 Mating
Operating and storage temperature	(°C)	-40-+80
Relative humidity	%	95

Characterstic
•Zirconia Sleeve ,Compact design.
•Low insertional loss, High return loss.
•High precision of mechanical dimensions.
•High reliability & stability.

Application

•Telecommunication Networks.
•Fiber Optic Sensors
• Local Area Network.
•Test & measurement.
•FTTH and FTTX.
•DWDM applications

Sc APC Upc Fiber Optic Adapter Singlemode Multimode Square Solid Metal Adapter Coupler

Jiangsu Dierite Optoelectronics Technology Co., Ltd. is a professional optical fiber cable manufacturer with own R&D center; marketing center and production base, located in Changzhou Jiangsu China, close to Shanghai and Ningbo port. Our company is committed to provide first-class solutions and OEM services for operaton system integrators and Integrated wiring provider Products cover indoor and outdoor fiber optic cable, fiber optic patch cord, PLC splitter; adaptecattenuatocetc.
Dierite was established in 2010, now our workshop area is about 5000 square meters, and has more than 150 workers. We are also a national high-tech enterprises with ISO 9001_,CE_/RoHS and many Utility Model Patent Certificates. Our factory controls the quality constantly and strictly in order to give the best products to the users.
Products have been widely used in telecommunications, broadband, and network industry and are exported to Asia, North America, South America, Europe and other places. As an original manufacturer; we will accelerate the development of the global 5G era with the most stringent quality and the most competitive price.
